Product Details
● Type: Audio XLR Combo 6.35mm Mono Jack Socket Connector
● Material: High quality plastic and metal material
● Allow for Male XLR and 1/4″ Connection
● Eliminates need for separate connectors
● Applied to Audio-Video Equipment, Microphone, Sound Card, Video, Mixer, Power Amplifier, Speaker and Stage Sound Lighting etc
Specification
| Product Name |
Audio XLR Combo 6.35mm Mono Jack Socket Connector |
| Model |
CTCK-11W |
| Pin |
3 Pole |
| Contact Resistance |
XLR＜10 MΩ ; Jack＜20 MΩ |
| Insulation Resistance |
＞500 MΩ |
| Withstand Voltage |
1600V, AC/min |
| Terminal Strength |
≥30 N |
| Rated Load |
50V AC 7.5A |
| Temperature |
-20 ~ +65 ℃ |
| Life |
5000 Time |
-
